6.15 Transport System
The transport system is an optional feature that requires frequent checks and maintenance to ensure reliable operation.
Refer to 7.4.3 Stabilizer / Slow Speed Transport Wheels, page 514 for more information.
6.15.1 Checking Wheel Bolt Torque
The transport wheel bolt torque should be checked after one operating hour following the installation of the wheels, and
every 100 operating hours thereafter.
Figure 6.319: Bolt Tightening Sequence
1. Torque wheel bolts to 120 Nm (90 lbf·ft) using the
sequence shown at right.
IMPORTANT:
Whenever a wheel is removed and reinstalled, check the
wheel bolt torque after one hour of operation and every
100 hours thereafter.
