214323 168 Revision B
10237391023739
A
Figure 4.80: Height Adjustment Knob on Combine
Control Console
The selected AHHC height is adjusted using HEIGHT
ADJUSTMENT knob (A) on the control console. Turning the knob
clockwise increases the selected height. Turning the knob
counterclockwise decreases the selected height.
4.8.5 Adjusting Header Raise/Lower Rate – Challenger
®
6 Series
The speed at which the header rises or falls can be adjusted on a Challenger
®
6 Series combine.
NOTE:
Changes may have been made to the combine controls or the display since this document was published. Refer to the
combine operator’s manual for the most up-to-date information.
1003666
Figure 4.81: Challenger
®
Combine Display
1. Press the header icon on the FIELD page. The HEADER page
appears.
AUTO HEADER HEIGHT CONTROL
