214323 142 Revision B
Figure 4.20: Combine Controls
1. Use HEADER SETTINGS key (A) to display the HEADER
SENSITIVITY CHANGE page.
2. Use UP (B) or DOWN (C) keys to adjust the highlighted item.
The height sensitivity setting range is 0 (least sensitive) to
250 (most sensitive) in increments of 10.
NOTE:
Adjustments take effect immediately. Use the CANCEL key
to return to the original settings.
3. Use HEADER SETTINGS key (A) to highlight the next
changeable item.
4. Use ENTER key (D) to save the changes and return to the
monitor page. If there are no changes, the screen will
return to the monitor page after 5 seconds.
Figure 4.21: Height Sensitivity Change Page
AUTO HEADER HEIGHT CONTROL
