MacDon FlexDraper FD75 - Page 284

214323 266 Revision B
1003464
A
B
Figure 4.278: Float Indicator Box (5 Volt AHHC Sensor
Assembly Shown)
3. Adjust cable take-up bracket (B) (if necessary) until
pointer (A) on the float indicator is on 0.
4. Ensure that the header float is unlocked.
1003672
A
Figure 4.279: New Holland Combine Display
5. Select DIAGNOSTICS (A) on the main page. The
DIAGNOSTICS page appears.
6. Select SETTINGS. The SETTINGS page appears.
1003673
A
Figure 4.280: New Holland Combine Display
7. Select GROUP drop-down arrow (A). The GROUP dialog box
appears.
AUTO HEADER HEIGHT CONTROL
