Figure 1.19: Endsheets, Reel Arms, Backsheet
A - MD #131393 (2 Places) B - MD #174632 (2 Places)
C - MD #184422 (Single Knife – Left Side Only; Double Knife – Both Sides) D - MD #184422 (Single Knife – Left Side Only; Double Knife – Both Sides)
E - MD #131392 (Double Reel 2 Places) F - MD #131391 (2 Places)
G - MD #174436 H - MD #131393 (Single Reel – 2 Places)
