Driveline and driveline
universals
▲
Knife drive box oil - first 50
hours only
S
All upper cross auger (UCA)
grease points
100 Hours or Annually
35
ü
Auger to pan and feed
draper clearance
ü
Draper seal
ü
Gearbox lubricant level
ü
Reel drive chain tension
ü
Reel tine/cutterbar
clearance
ü
Knife drive belt tension
ü
Wheel bolt torque
ü
Knife drive box
lubricant level
ü
Knife drive box
mounting bolts
S
Auger drive chain
S
Float pivots
S
Float spring tensioners
S
Reel drive chain
Maintenance
Record
Action:
üü - Check
SS - Lubricate
▲▲ - Change
250 Hours or Annually
35
ü
Draper seal
S
Adapter auger pivots
S
Reel drive U-joint
S
Bell crank linkage
S
Transport axle pivot
bushings
▲
Hydraulic oil filter
500 Hours or Annually
35
ü
Draper seal
S
Reel shaft bearings
S
Stabilizer/slow speed
transport wheel bearings
ü
Gearbox chain tension
1000 Hours or 3 Years
35
▲
Knife drive box lubricant
▲
Gearbox lubricant
▲
Hydraulic oil
