MacDon FlexDraper FD75 - Page 456

214323 438 Revision B
1018205
A
B
C
Figure 6.178: Feed Deck Polyethylene Door
5. Rotate latches (A) to unlock handles (B).
6. Hold pan (C) and rotate handles (B) downward to
release pan.
1018204
A
Figure 6.179: Feed Deck Polyethylene Door
7. Lower plastic pan (A) and check for debris that may have
fallen under the adapter draper.
MAINTENANCE AND SERVICING
