Table 3.2 FD75/CA25 Combine Header Recommended Settings (continued)
Crop Type
Stubble
Height
mm (in.)
Crop
Condition
Divider
Rods
Draper
Speed
Setting
18
Header
Angle
1920
Reel
Cam
Reel
Speed
%
21
Reel
Position
Skid Shoe
Position
20
Stabilizer
Wheels
22
Upper
Cross
Auger
California
Rice
102–203
(4–8)
Light
Rice
divider
rod
17
4D310–15 6 or 7
Middle or
down
As required
20
Not
required
California
Rice
102–203
(4–8)
Normal
Rice
divider
rod
17
4B– C3106or7
Middle or
down
As required
20
Not
required
California
Rice
102–203
(4–8)
Heavy
Rice
divider
rod
17
4B– C3106or7
Middle or
down
As required
20
Not
required
California
Rice
102–203
(4–8)
Lodged
Rice
divider
rod
17
4D45–10 6 or 7
Middle or
down
As required
20
Not
required
California
Rice
203+ (8+)
Light
Rice
divider
rod
17
4A310–15 6 or 7
Not
applicable
As required
20
Not
required
California
Rice
203+ (8+)
Normal
Rice
divider
rod
17
4B– C3106or7
Not
applicable
As required
20
Not
required
California
Rice
203+ (8+)
Heavy
Rice
divider
rod
17
4B– C3106or7
Not
applicable
As required
20
Not
required
California
Rice
203+ (8+)
Lodged
Rice
divider
rod
17
4D45–10 6 or 7
Not
applicable
As required
20
Not
required
Delta Rice
51–152
(2–6)
Light
Off
6D2or310–15 6 or 7
Middle or
down
As required
20
Not
required
Delta Rice
51–152
(2–6)
Normal Off
6B– C 2 or 3 10 6 or 7
Middle or
down
As required
20
Not
required
OPERATION
18. Setting on CA25 draper control. 19. Set header angle as shallow as possible (setting A) with center-link and skid shoes while maintaining cutting height. 20. Cutting height is controlled with a combination of skid shoe settings and header angle. 21. Percentage above ground speed. 22. Stabilizer wheels are used to minimize header bouncing and to limit side-to-side movement when cutting off the ground in rolling terrain.
