Hardware
108
Refer to “Connection” for how and where each connector is connected.
(1) ID Button
A button to light the ID LED. Pressing the button lights and pressing again turns the
LED off (it functions similarly to the ID button of EXPRESSSCOPE® Monitor in front
side of the server).
(2) Reset Button
This button is used for resetting the management module.
(3) USB Port
(4) USB Port
This connects to a device that supports the USB 2.0 (Hi-speed) interface.
(5) USB Port (for maintenance)
USB connector for maintenance. This is not commonly used.
(6) Monitor Connector (VGA)
This connects display devices.
(7) Serial Connector (RS-232C D-sub 9pin)
This connects to a device that has a serial interface.
(8) 10BaseT/100BaseTX/1000BaseT LAN Connector
(LAN management for customers)
This is used for connecting Web Console.
(9) 10BaseT/100BaseTX LAN Connector
(Maintenance LAN for maintenance service personnel)
(10) 10BaseT/100BaseTX/1000BaseT LAN Connector
(11) 10BaseT/100BaseTX/1000BaseT LAN Connector
NOTE:
(2) Shutdown Button
(3) Management Module Reset Button
The above two buttons can be pressed by a sharp-pointed object.
