2.13 Virtual LCD
Virtual LCD is displayed by selecting “Virtual LCD” from the menu on the left side of the screen.
LCD and LED information in the server is displayed in Virtual LCD.
(1) Show displayed contents of virtual LCD.
(2) Show displayed contents of virtual LED.
Status
Power
2.13.1 Virtial LCD Information
This menu displays the latest failure information of the server.
Display Example 1 (threshold value of the sensor)
(1) (2) (3)
MG1 1.8Vs Alm XX
(1) MG1 : The name of the parts which occurred a faulire.
MG = Management module (MGM)
PM = Processor Memory module(PMM)
(2) 1.8Vs: The power level which caused the failure. (or the temperature)
(1)
(2)
