NEC Express 5800 - PCI Card Mounting Rule

Hardware
101
PCI Card Mounting Rule
(1) PCI slot 1 ················ RAID supported slot *1
(2) From rear left
PCI slot 2 ················ WOL supported slot *2
PCI slot 3
PCI slot 4
PCI slot 5
PCI slot 6
PCI slot 7 ················ x16, Middle size supported slot *3
RAID supported slot if A1040a *1
(3) From rear left
PCI slot 8 ················ WOL supported slot *2
PCI slot 9
PCI slot 10
PCI slot 11
PCI slot 12
PCI slot 13 ·············· x16､Middle size supported slot *3
(4)·· PCI slot 14 RAID supported slot *1
(5) Management Module 1
(6) Management Module 2 if A1080a-D
Supported Functions Supported PCI Slots
*1
SAS RAID Card Supported
PCI slot 1
PCI slot 7 if A1040a
PCI slot 14
*2
Wake On Lan (WOL) Supported
PCI slot 2
PCI slot 8
*3
Middle size and PCIe x16 Supported
PCI slot 7
PCI slot 13
IMPORTANT:
● Other PCI cards can also be mounted to the slot when the
functions in the above table are not used.
IMPORTANT:
● The default setting of OPROM for PCI slot7 is Disabled if A1040a.
Change the setting to Enable when using SAS RAID card on PCI
slot7 in A1040a model referring “Slot Configuration” of the “BIOS
Setu
p
” section in thie User’s Guide.
