510
Resource Web Console
To connect to Resource Web Console, enter IP address set in the address field by going to “Box
-> Box Network Menu” from EXPRESSSCOPE® Monitor after starting the browser. The set IP
address can be checked by going to “Box -> Box Network Menu -> View Information.”
It is possible to connect to resource Web console by connecting to system Web console and
clicking Resource name in display items for “Power Consumption by BaseModule” in
Summary.
3.1 Summary
Summary is displayed by selecting “Summary” from the menu on the left side of the screen.
The status of resource can be checked in Summary. Displayed information is automatically
updated in Summary.
(1) Displays resource status and (2) displays hardware status.
The following is the description on each item displayed in Summary.
(1) Resource Status
Display resource status.
Power : Power status
Display (value) Description
Off DC power of all Server is OFF.
On DC power of at least 1 Server is ON.
(1)
(2)
