42
Feature of Each Model
There are 3 types of models for the server.
● A1080a-S Model
● A1080a-D Model
● A1080a-E Model
● A1040a Model
A1080a-S Model,A1040a Model
A1080a-S model and A1040a model can mount up to four processors. The memory
configuration is from 4GB (2GB x 2) for the minimum to 1TB (16GB x 64) for the maximum.
At least one processor memory module is required for A1080a-S model and A1040a model.
A1080a-S model and A1040a model aim to improve performance by reducing the QPI (Quick
Path Interconnect) connection of lower number processor memory modules #1, #2, #3 and #4 in
the server of A1080a-E model, and by increasing the QPI connection instead. The following
configuration is available for this model.
Only Server 1 is configured on A1080a-S model or A1040a model.
* PMMx is an abbreviation of a processor memory module.
* IOHx is an abbreviation of an I/O hub.
* ICH is an abbreviation of an I/O control hub.
PMM1
PMM3
PMM4
PMM2
IOH1
IOH2
ICH
Server 1
