Hardware
119
network port. Lighting in amber indicates that 1000 Mbps is used. Lighting in green
indicates that 100 Mbps is used. LED that is off indicates that 10 Mbps is used.
Power Supply Unit LED
The following table shows LED status and its description.
LED Status Description
Off AC Power off
Blinking in green DC Off status
Lighting in green DC On, normal power supply module
(1)
Lighting in amber Abnormal power supply module
Rear of Server
(1)
(1) PSU Status LED
