Hardware
192
Installation
Install the DVD drive by following the procedure shown below.
1. Refer to “Preparation for Mounting/Unmounting” for preparation.
2. Insert the DVD drive into the DVD slot.
3. Push the DVD drive inward completely until the lock levers on the right and left side of the
DVD drive are locked with a clicking sound.
4. Refer to “System Diagnostics” in Operation and Maintenance to perform the diagnostic
test.
5. Clear the maintenance mode set in step 1.
IMPORTANT:
Pull out the DVD drive horizontally. The DVD drive or internal
connector may be damaged if it is inclined or pressure is added
from side to side and up and down while pulling out.
To Next Page
