Hardware
197
Remounting Server to Rack
Push the release levers on the rails on the sides of the server and clear the latched status to
remount the server to the rack. Be very careful not to catch your finger at this time.
1. Push the release levers on the rails on each side of the server and clear the latched status.
2. Insert this sever into the rack.
3. Tighten four screws on each font end of the server and loosened in step 3 of “Pulling Out
Server from Rack.”
4. Uninstall the stabilizer that was mounted to the bottom front of the rack.
5. Clear the maintenance mode set in step 1 of “Pulling Out Server from Rack.”
Release Lever
To Next Page
