Hardware

190

DVD Drive

Uninstallation

Uninstall the DVD drive by following the procedure shown below.

1. Refer to “Preparation for Mounting/Unmounting” for preparation.

2. Push the 2 lock levers inward located on the right and left side of the DVD drive.
