Serial Port 1 Configuration
The following screen is displayed by selecting “Serial Port 1 Configuration” in Super I/O
Configuration menu.
Refer to the following table for the items.
Item Parameter Description
Serial Port Enable Disabled
[Enabled]
Set Disable/Enable for serial
port 1.
Serial Port Setting - Display base address and
interruption of the currently set
serial port 1 (display only).
Change Settings [Auto]
IO=3F8h; IRQ=4;
IO=3F8h; IRQ=3,4;
IO=2F8h; IRQ=3,4;
IO=3E8h; IRQ=3,4;
IO=2E8h; IRQ=3,4;
Set base address and
interruption of the currently set
serial port 1.
When Auto is specified, setting
is automatically performed by
BIOS.
[ ]: Factory default
