Hardware
204
NEC EXPRESSSCOPE® Monitor
NEC EXPRESSSCOPE® Monitor
With EXPRESSSCOPE® Monitor, it is possible to turn ON/OFF the power of the server, check
the system information or status, and set each network.
EXPRESSSCOPE® Monitor is located on the bottom front left of the server.
NEC EXPRESSSCOPE® Monitor Operation Method
(1) LCD : Abbreviation of Liquid Crystal Display.
(2) ID Button (Front) : Enables a user to light or turn off the ID LED.
ID LED can be lit by pressing the button while the ID LED is off.
ID LED can be OFF by pressing the button while the ID LED is
lighting.
(3) Navigation Button : Operates the cursor displayed on LCD.
(1)
(2)
(3)
EXPRESSSCOPE® Monitor
To Next Page
