NEC Express 5800 - Internal Hard Disk Drive

Hardware
109
Internal Hard Disk Drive
A hard disk drive is sold separately.
Pay careful attention to handle the hard disk drive in which operating system or software is
installed.
(1) Hard Disk Drive
(2) Connector
This connector connects to the server.
(3) Drive Carrier
(4) Disk Access LED
(5) Lever
A lever to unlock the handle when removing the hard disk drive.
(6) Handle
A handle to hold for installing/uninstalling the hard disk drive.
(4)
(6)
(5)
(3)
(2)
(1)
