Processor Memory Modules Adding/Mounting Rule
The following describes how to mount processor modules when adding the modules.
Rules of Adding Processor Memory Modules
For A1080a-S,A1040a Model
 Processor Memory Module #1 is required.
 Add in the order of lowest to highest number, i.e., #2, #3, and #4.
For A1080a-D Model
 Processor Memory Modules #1 and #5 are required.
 Add in the order of lowest to highest number of each server, i.e., #2, #6, #3, #7, #4, and #8.
Processor Memory
Module Number
Order of
Mount Slot
#1 #2 #3 #4
#5 #6 #7 #8
First ● - - - -
Second ● ■ - - - -
Third ● ♦ ■ - - - -
Fourth ● ♦ ♦ ■ - - - -
Processor Memory
Module Number
Order of
Mount Slot
#1 #2 #3 #4 #5 #6 #7 #8
First ● ●
Second ● ■ ●
Third ● ♦ ● ■
Fourth ● ♦ ■ ● ♦
Fifth ● ♦ ♦ ● ♦ ■
Sixth ● ♦ ♦ ■ ● ♦ ♦
Seventh ● ♦ ♦ ♦ ● ♦ ♦ ■
IMPORTANT:
Note that the rule of adding modules differs depending on the
model such as A1080a-S, A1080a-D, and A1080a-E.
●: Required
♦ : Already Mounted
■: Adding
● : Required
♦ : Already Mounted
■ : Adding
IMPORTANT:
A1080a-D model can adopt a different configuration for each
server by using the configuration change service at the time of
p
urchase.
IMPORTANT:
When the Processor Memory Module is added or exchanged,
it is necessary to set "Core Status" from System Web Console.
Refer to Setting CoreStatus.
