Server Menu
View Information Screen
When selecting and executing “View Information” in the Server Menu status, the screen
moves to View Information.
Scroll the View Information Screen to next or previous screen with “Up” or “Down” button.
Press “OK” button to return to Server Menu.
The top right edge “↑” display or bottom right edge “↓” display is the indication of other
information available on that direction.
The following information is displayed.
(1) Server Name : Server Name registered by customer
When the Server Name is 21 characters or longer, the
last 2 of the 20 characters are displayed as “..”
(2) Server Number : Server Number [1] or [2] is displayed.
(3) Server Power State : DC Power status of the applicable server is displayed.
(4) Server Operating State : Server State Sensor status is displayed.
(5) Health : Server Health State
“Normal” : Normal or Monitor
“Warning” : Non-Critical
“Critical” : Critical
(6) Chassis Code : System Progress(internal use)
(7) Master CLK : CLK Number [1] or [2] currently assigned for Master in
the applicable Server is displayed. (internal use)
(8) No Degraded Boot Mode state : Allow or Not Allow degraded boot of the applicable
Server is displayed.
As the previous page, it is displayed on the LCD panel
of EXPRESSSCOPE®
Monitor only when it is not
allowed.
(7)
M a
s t e
r
C
L
K
:1
↑
N o
D e
g r
a d e
B
oo t
(8)
(1)
(4)
(3)
(2)
E x
p 5 8
0 0
Se
rv
er
Sy
s. .
S V
R 1
Po
we
red
O
ff
M F
In
i t
i a l
iz
ing
W a
r n i
n g
5B
7D
_
02
4A
↓
(6)
(5)
To Next Page
