381
System Web Console
To connect to System Web Console, enter IP address set in the address field by going to
“System -> SYS Network” from EXPRESSSCOPE® Monitor after starting the browser. The set
IP address can be checked by going to “System -> SYS Network -> View Information”.
1.1 Summary
Summary is displayed by selecting “Summary” from the menu on the left side of the screen.
The status of system, server and resource can be checked from Summary. Display information is
automatically updated in Summary.
(1) displays system status, (2) displays server status, and (3) displays resource status.
The following is the description on each item displayed in Summary.
System Name : Display system name. “N/A” is displayed when it is not set.
Firmware Version : Display version for Management Firmware.
(1) System Health
Display system status.
Name : System name
Power : Power status
Display (value) Description
(1)
(2)
(3)
To Next Page
