Hardware
189
Adding Power Supply Unit
1. Unlock and remove the dummy cover from the power supply unit slot to be added.
2. Mount the power supply unit. Confirm that it is inserted completely and locked with a clicking
sound.
3. Install the power code and fix the cable with the repeat ties for preventing from falling off.
NOTE:
When the power supply unit is added while the power is ON
(Online), the Status LED lights in green after the power supply unit
is added followed by the power code is connected.
On the other hand, when the power supply unit is added while the
DC power is OFF (Offline), the Status LED blinks in green after the
power code is connected. And it lights when the DC power is
turned ON.
To Next Page
