Hardware
243
Server Menu
Enter Password Menu
When LCD Guard Mode is set to “Enable,” the screen moves to Enter Password Menu by
selecting and executing “SVRx Control >” in the Server Menu status.
Select “Up” or “Down” button to change numbers on the cursor one by one in the range from
0 to 9. Default value is se to All 0.
Select “Left” or “Right” button to move the cursor from side to side.
When pressing “OK” button, the screen moves to Server Menu. Server Control Menu (previous
page) if the entered value matches the password.
When it does not match, Password Not Match Screen (below image) is displayed.
(1) Server Number : Server Number [1] or [2] is displayed.
Press “OK” button to return to Main Menu.
S
V R
1
Con
tr
ol
P
a s s
w o
rd
No
t M
at
ch
(1)
E
d
n
t e
r
Pas
sw
or
0
0 0 0
IMPORTANT:
When forgot the password, reset the SG information of the
management firmware using Resource Web Console.
