A1080a-E Model
A1080a-E model is configured with eight processors.
The memory configuration is from 8GB (2GB x 4) for the minimum to 2TB (16GB x 128) for the
maximum.
A1080a-E model aims to improve expandability of I/O interface by reducing the QPI (Quick Path
Interconnect) connection, and by connecting the lower number processor memory modules #1,
#2, #3 and #4 and higher number processor memory modules #5, #6, #7 and #8 in the server of
A1080a-D model described in the previous page.
Only Server 1 is configured on A1080a-E model.
* PMMx is an abbreviation of a processor memory module.
* IOHx is an abbreviation of an I/O hub.
* ICH is an abbreviation of an I/O control hub.
Server 1
PMM1
PMM3
PMM4
PMM2
IOH1
IOH2
ICH
PMM6
PMM8
PMM7
PMM5
IOH3
IOH3
