Hardware
209
Executing “Return” enables to return to the main screen.
The top right edge “↑” display or bottom right edge”↓” display is the indication of other
information available on that direction.
The “ > ” display at the end of each item indicates there are its sub menus hidden under it.
If no button operation is performed for a certain period of time in the Main Menu status or its
sub menu status, the screen returns to the main screen automatically.
“View Faults” is displayed only when there is a failed module/unit in the system.
For A1080a-D model, “Server 1” is not displayed while the firmware of the management
module is being rebooted.
“Server2” is displayed for A1080a-D model only. For A1080a-D model, it is not displayed while
the firmware of the management module is being rebooted.
