Hardware
274
(1) Network Address for System Web Console
System Set IP Addr ← 192.168.1.1
Set IP Mask ← 255.255.255.0
Set Gateway Addr ← 192.168.1.254
(2) Network Address for Server Web Console
Server 1 Set IP Addr ← 192.168.1.100
Set IP Mask ← 255.255.255.0
Set Gateway Add ← 192.168.1.254
When Server 2 exists in A1080a-D model
Server 2 Set IP Addr ← 192.168.1.101
Set IP Mask
← 255.255.255.0
Set Gateway Addr
← 192.168.1.254
(3) Network Address for Resource Web Console
Box Set IP Addr ← 192.168.1.200
Set IP Mask
← 255.255.255.0
Set Gateway Addr
← 192.168.1.254
* The above address is the factory-default value. When multiple servers exist, set the
appropriate address according to the environment to avoid duplicated addresses.
IMPORTANT:
IP addresses shown below are not available as they are already
reserved within the server.
The server having the following IP addresses cannot access to the
system of this server via the router (L3SW).
•
172.24.0.0/16 (172.24.0.0 ~ 172.24.255.255)
• 172.16.0.0/16 (172.16.0.0 ~ 172.16.255.255)
