411
Display or set Valid (Enable/Disable)/Invalid by Core unit.
(4) Selecting the server enables to display or set in “Server.”
MAX Valid Core Count : The maximum number of cores which can be in valid status in the
applicable server
(5) Display Valid (Enable/Disable)/Invalid of each core in the applicable server.
Core status can be changed by operating radio button.
IMPORTANT:
Core number of each core is not same by processor.
After PMM replacing/inserting/removing, provisional core
number will be assigned to the cores. These core number are
displayed in ascending order. After DC-ON, formal core number
will be assigned
After PMM is replaced
(PMM includes PROC1)
PROC CORE
1 2
1 3
1 4
1 5
1 6
1 7
1 8
1 9
1 10
1 11
Total
Cores=10
After DC ON
PROC CORE
1 1
1 2
1 3
1 4
1 5
1 6
1 7
1 8
Total
Cores=8
