421
SMTP Server Address screen
Set IP address for SMTP server.
(14) IP address of send mail server can be displayed and changed in “Mail Server
(SMTP)IP.”
Set the address in dot-decimal notation to IP address.
Dot-decimal notation: xxx.xxx.xxx.xxx (0-255)
(15) Checking the checkbox for “Port No” enables to set port number of the mail server.
Settable Port No: 1-65535
(16) Selecting the checkbox for “User Name” to set login name, password and authentication
method for send mail server.
(16)-1 Select authentication type in “Authentication.”
Selection Options
None
PLAIN
LOGIN
CRAM-MD5
(15)
(16)-2
(18)-1
(14)
(16)-3
(16)-1
(19)-1
(19)-2
(20)-1
(20)-2
(17)
(18)-2
(19)-3
