Status : Status
IMPORTANT:
 When a pair of DIMMs are not configured in the PAIR, the fault
sensor information such as “Name : PMMx DIMMpy
(x=1-8),y=1-8)” for the PAIR will not be displayed.
IMPORTANT:
 SAS slot sensors for SAS slot will be displayed after PCI slot
sensors. The PCIe slot sensor name begins from
PCIeSlot02/PCIeSlot08. PCIe and SAS slot sensors name is as
follows.
 A1080a-S/A1080a-E/A1080a-D Model
PCIeSlot02 - PCIeSlot07: PCIe slot
PCIeSlot01 : SAS slot
PCIeSlot08 - PCIeSlot13: PCIe slot
PCIeSlot14 : SAS slot
 A1040a Model
PCIeSlot02 - PCIeSlot06: PCIe slot
PCIeSlot07 , PCIeSlot01: SAS slot
