Software

581

Uninstallation

Execute ez_uninst.sh under the installation directory of this utility.

All the under of the ezclct directory that the installer made when installing it is deleted.

# cd /hoge

# ls

ezclct

# ezclct/ez_uninst.sh

# ls

↑

The ezclct directory is deleted.
