(5) Read the information on the Monitoring Event Log screen as necessary since information
listed here needs to be collected in the next procedure.
To collect event log data, right-click on the Event Log screen and select “Select All (A)”.
Then, right-click and select “Copy (C)”. Paste the data on the text editor. Up to 100 event
logs can be displayed at one time. Select a full-screen mode when there are 100 or more
event logs.
(6) Repeat steps from 1 to 5 above for all WEB Consoles that need to be confirmed.
4. BID（Build In Diagnostic）Screen to show the failure on the suspected part
＜Description＞
BID : *********** Analysis Result *********************************************
1
BID : ----------- Fault Analysis Result ---------------------------------------
No. 1 DIMM [PMM0/DIMM000 ] 90%
No. 2 PMM [PMM0 ] 10%
2
BID : ----------- Fault Analysis Result (Component) ---------------------------
No. 1 ----- DIMM [PMM0/DIMM000 ] 90%
No. 2 ----- PMM [PMM0 ] 10%
3
BID : ----------- Error Information -------------------------------------------
PROC100 Memory single-bit ECC error occurred.
CELL1/PMM0/DIMM000 ADDRESS=0x0012_77FE_AF80 ECC_INFO=0x8890
Main memory DIMM patrol read data error occurred.
DIMM error information. SDRAM=No.D14, Signal(s)=DQ47
4
BID : ----------- Register Dump -----------------------------------------------
PROC100 EVENT=0004 SSB=04 AT0=000000_00000000 AT1=000004_00000000 TRN=0
BID : *************************************************************************
Replacement FRU/CRU：
The suspected failure percentage of the part is displayed based on the number of units to be
replaced when a failure occurs. The higher the suspected failure percentage for a part is, the
higher the possibility that the part is the cause of failure. However, the sum of the percentage
may not be 100, since after the decimal point is rounded off. The name of the part identified in
No.1 of the BID is displayed in View Faults of the LCD.
BID : ----------- Fault Analysis Result -----------------------------
No. 1 DIMM [PMM0/DIMM000 ] 90%
No. 2 PMM [PMM0 ] 10%
Whether to replace a part is determined here.
CRU：Customer Replaceable Unit
FRU：Field Replaceable Unit
Part name
Location
Suspected failure percentage
To Next Page
