Express5800/A1080a-E
NE3100-101H/C
1
（
8 sockets
）
Intel® Xeon®
processor
E7-8830 *1
Intel® Xeon®
processor
E7-8850 *1
Intel® Xeon®
processor
E7-8870
2.13GHz 2GHz 2.4GHz
0/8
30MB
8C/16T
Intel® 7500 *2
-
(
essential
)
/ 2TB
(
128x 16GB
)
*3
DDR3L Re
g
istered DIMM
ECC, SDDC,DDDC
supported
supported
(
between sockets mirrorin
g
）
2.5 HDD: SAS 10.8TB (12x 900GB)
supported
SAS 6Gb/s : RAID 0/1/5/6/10/50/60
DVD-ROM or DVD multiple drive (essential) *4
12x PCI EXPRESS 2.0 (x8 lanes, x8 sockets)(full height,167.6mm) *5
2x PCI EXPRESS 2.0
(
x16 lanes, x16 sockets
)(
full hei
g
ht,240mm
)
XGI Volari Z9s / 64MB
16770K colors: 800x600, 1,024x768, 1,280x1,024
1x Analog RGB (Mini D-Sub15, 1x Rear) , 1x Serial port (RS-232C/D-Sub9),
5x USB2.0
(
2x Front,2x Rear,1x Internal
)
*6
2x 1000BASE-T LAN (1000BASE-T/100BASE-TX/10BASE-T, RJ-45, 2x Rear)
1x Mana
g
ement LAN
(
1000BASE-T/100BASE-TX/10BASE-T, RJ-45, 1x Rear
)
supported
(
optional
)
supported(standard)
448 x 714 x 307 mm (w/o protuberance/inner rail)
482.6 x 848 x 307 mm(including protuberance/inner rail)
75.1kg [79.2kg]
4x 2200W((200V)/1100W(100V) 80 PLUS® GOLD (Hot plug supported)
AC200V±10%/AC100V±10%, 50/60Hz±3Hz
1655VA / 1622W 1695VA / 1662W 1695VA / 1662W
3374VA / 3307W 3574VA / 3503W 3574VA / 3503W
1693VA / 1659W 1734VA / 1699W 1734VA / 1699W
3451VA / 3315W 3656VA / 3511W 3656VA / 3511W
operating: 10
～
35
℃
*7 / 10
～
80%, non-operating: -10
～
55
℃
/ 20
～
80%
(
non-condensin
g)
EXPRESSBUILDER(NEC ESMPRO Manager, NEC ESMPRO Agent,
User's Guide
(
Online document
)
, Startup Guide, Rack rail
Windows Server® 2008 R2 Enterprise/Datacenter (SP1)
Red Hat® Enterprise Linux® 5.6 or later (EM64T)
Red Hat® Enterprise Linux® 6.1 or later (x86_64)
VMware® ESX® 4.1/VMware® ESXi™ 4.1
VMware® ESXi™ 5.0
NOTE:
Expansion slot Depth of the IO board which can be installed into expansion IO slot is 240mm for middle-size board and
167.6mm for short-size board.
ANNOTATION:
*1 CTO production. Lead time is different from standard products.
*2 For the memory buffer, Intel® 7512 Scalable Memory Buffers,which consume low power, are used.
*3 The max capacity of the memory depends on OS.
*4 Writin
g
software is not provided. DVD multiple drive is not supported in Linux.
*5 When using internal HDD, 1 slot must be assigned for RAID controller per 6 HDDs.
If 7 or more HDDs are used, 2 slots must be assigned for RAID controllers.
*6 Can be used for keyboard and mouse on front or rear ports.
*7 Can operate under 40℃ with limited configuration.
*8 The latest information of supported OS is shown in following URL
http://www.58support.nec.co.
j
p/
g
lobal/download/index.html
Supported OS *8
Major Appendant Parts
Power Consumption(100V, Standby)
Power Consumption(100V, High Load)
Graphics
Chip / Video RAM
1066MHz
24MB
10C/20T
3rd Cache
Number Core/Thread
Environmental Requirement
Redundant Fan
Dimensions (WxDxH)
Weight (Max.)
Power Supply
Power Consumption(200V, Standby)
Power Consumption(200V, High Load)
Color, Resolution
Additional Slot
Standard Interface
Redundant Power Supply
Interface / RAID level
Optical Drive
Drive BayAuxiliary
Storage
Device
Max.
Hot-swap
Chipset
Memory
Capacity Standard/Max.
Type
Clock
Error Detection, Recovery
Online Spare Memory
Memory Mirroring
Model Name
Product Code
Number of Server
CPU
Type
Clock
Number Standard/Max.
