Express5800/A1080a-D
NE3100-002H/C
2 （Max. 4 sockets）
Intel®
Xeon®
processor
E7520 *1
Intel®
Xeon®
processor
E7540
Intel®
Xeon®
processor
X7542 *1
Intel®
Xeon®
processor
L7545 *1
Intel®
Xeon®
processor
X7550
Intel®
Xeon®
processor
L7555 *1
Intel®
Xeon®
processor
X7560
1.86GHz 2GHz 2.66GHz 1.86GHz 2GHz 1.86GHz 2.26GHz
0/4 per serve
r
18MB 24MB
4C/8T 6C/12T 6C/6T 6C/12T 8C/16T
Intel® 7500
- (essential) / 1TB (64x 16GB) *2 per serve
r
DDR3L Registered DIMM
800MHz 1066MHz 978MHz 1066MHz 978MHz 1066MHz
ECC, SDDC
supported
supported (internal socket, between sockets mirroring）
-
2.5 HDD: SAS 5.4TB (6x 900GB) per serve
r
supported
SAS 6Gb/s : RAID 0/1/5/6/10/50
(server common)DVD-ROM or DVD multiple drive (essential) *3
-
-
6x PCI EXPRESS 2.0 (x8 lanes, x8 sockets)(full height 167.6mm) per server *4
1x PCI EXPRESS 2.0 (x16 lanes, x16 sockets)(full height 240mm) per serve
r
XGI Volari Z9s / 64MB per serve
r
16770K colors: 800x600, 1,024x768, 1,280x1,024
1x Analog RGB (Mini D-Sub15, 1x Rear) per server,
1x Serial port (RS-232C/D-Sub9) per server,
3x USB2.0 (2x Rear,1x Internal) *5 per server
2x USB2.0 (2x Front) *5 server common
2x 1000BASE-T LAN (1000BASE-T/100BASE-TX/10BASE-T, RJ-45, 2x Rear) per server
1x Management LAN (1000BASE-T/100BASE-TX/10BASE-T, RJ-45, 1x Rear) per serve
r
supported(optional)
supported(standard)
448 x 714 x 307 mm (w/o protuberance/inner rail)
482.6 x 848 x 307 mm(including protuberance/inner rail)
75.5kg [79.6kg]
(server common)2x 2200W((200V)/1100W(100V) 80 PLUS® GOLD (Hot plug supported)
AC200V±10%/AC100V±10%, 50/60Hz±3Hz
1705VA/
1671W
1842VA/
1806W
1885VA/
1848W
1705VA/
1671W
1885VA/
1848W
1705VA/
1671W
1885VA/
1848W
3576VA/
3504W
3696VA/
3622W
3896VA/
3818W
3576VA/
3504W
3896VA/
3818W
3576VA/
3504W
3896VA/
3818W
1744VA/
1709W
1884VA/
1847W
1928VA/
1890W
1744VA/
1709W
1928VA/
1890W
1744VA/
1709W
1928VA/
1890W
3658VA/
3585W
3780VA/
3704W
3985VA/
3905W
3658VA/
3585W
3985VA/
3905W
3658VA/
3585W
3985VA/
3905W
operating: 10～35℃*6 / 10～80%, non-operating: -10～55℃ / 20～80%
(non-condensing)
EXPRESSBUILDER(NEC ESMPRO Manager, NEC ESMPRO Agent,
User's Guide(Online document), Startup Guide, Rack rail
Windows Server® 2008 R2 Enterprise/Datacenter
Windows Server® 2008 Enterprise/Datacenter (x64,SP2)
Red Hat® Enterprise Linux® 5.5 or later (EM64T)
VMware® ESX® 4.0/VMware® ESXi™ 4.0
VMware® ESX® 4.1/VMware® ESXi™ 4.1
VMware® ESXi™ 5.0
NOTE:
Expansion slot Depth of the IO board which can be installed into expansion IO slot is 240mm for middle-size board and
167.6mm for short-size board.
ANNOTATION:
*1 CTO production. Lead time is different from standard products.
*2 The max capacity of the memory depends on OS.
*3 Writing software is not provided.
*4 When using internal HDD, 1 slot must be assigned for RAID controller per 6 HDDs.
*5 Can be used for keyboard and mouse on front or rear ports.
*6 Can operate under 40
℃
with limited configuration.
*7 The latest information of supported OS is shown in following URL
http://www.58support.nec.co.jp/global/download/index.html
Supported OS *7
Chipset
Memory
Capacity Standard/Max.
Type
Clock
Error Detection, Recovery
Online Spare Memory
Memory Mirroring
Model Name
Product Code
Number of Server
CPU
Type
Clock
Number Standard/Max.
3rd Cache
Number Core/Thread
Interface / RAID level
Optical Drive
FDD
Drive Bay
Standard
Max.
Hot-swap
Power Consumption(100V, Standby)
Device Bay
Graphics
Chip / Video RAM
Color, Resolution
Additional Slot
Standard Interface
Weight (Max.)
Power Supply
Power Consumption(200V, Standby)
Redundant Power Supply
Redundant Fan
Dimensions (WxDxH)
Auxiliary
Storage
Device
Power Consumption(200V, High Load)
Major Appendant Parts
Power Consumption(100V, High Load)
Environmental Requirement
