Hardware
94
A1080a-E Model:
Mirroring in the processor memory module: Not supported
Mirroring between processor memory modules: One of the following configurations is
supported.
(1) Processor Memory Modules #1 and #2, #3 and #4, #5 and #6, and #7 and #8
#3
#4
#1
#2
#7
#8
#5
#6
IMPORTANT:
●The size of a memory capacity displayed in OS is the one that
deducts a stand-by memory capacity from the capacity of all
physically mounted memories when using the memory
mirroring function (the size is half-capacity of the actual
memory when using the memory mirroring function.)
● Even if Mirroring in the processor memory module is set when
using A1080a-E model, the system will be booted with Mirroring
between processor memory modules.
However, the display on Server Web Console will be kept
indicating as Mirroring in the processor memory module
On the other hand, the message,”Memory Mirroring Setting was
changed” will be logged on the Event Log.
