Nortel BayStack 450-24T - Figure 1-46. Setting Port Priority Example

BayStack 450 10/100/1000 Series Switches
309978-D Rev 01 1-77
5. Select a priority level from the range shown in the Traffic Class
Configuration screen (or modify the Traffic Class parameters to suit your
needs).
6. Assign the priority level to ports using the VLAN Port Configuration
screen:
a. Press [Ctrl]-R to return to the VLAN Configuration Menu.
b. From the VLAN Configuration Menu, select VLAN Port
Configuration (or press c).
The VLAN Port Configuration screen opens (Figure 1-46).
Figure 1-46 shows the VLAN Port Configuration screen setup for port 4 in
Figure 1-43 on page 1-74.
Figure 1-46. Setting Port Priority Example
For more information about using this feature, see “VLAN Configuration Menu”
on page 3-44.
VLAN Port Configuration
Port: [ 4 ]
Filter Tagged Frames: [ No ]
Filter Untagged Frames: [ No ]
Filter Unregistered Frames: [ No ]
Port Name: [ Cathy’s port ]
PVID: [ 2 ]
Port Priority: [ 6 ]
Tagging: [ Untagged Access ]
Use space bar to display choices, press <Return> or <Enter> to select choice.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
