Figure 3-17. VLAN Configuration Menu
Table 3-13 describes the VLAN Configuration Menu options.
Table 3-13. VLAN Configuration Menu Options
Option Description
VLAN Configuration... Displays the VLAN Configuration screen (see “VLAN Configuration” on
page 3-46). This screen allows you to set up VLAN workgroups.
VLAN Port
Configuration...
Displays the VLAN Port Configuration screen (see “VLAN Port Configuration”
on page 3-52). This screen allows you to set up a specific switch port.
VLAN Display by Port... Displays the VLAN Display by Port screen (see “VLAN Display by Port” on
page 3-56).
Traffic Class
Configuration...
Displays the Traffic Class Configuration screen (see “Traffic Class
Configuration” on page 3-57).
Return to Switch
Configuration Menu
Exits the VLAN Configuration Menu and displays the Switch Configuration
Menu.
VLAN Configuration Menu
VLAN Configuration...
VLAN Port Configuration...
VLAN Display by Port...
Traffic Class Configuration...
Return to Switch Configuration Menu
Use arrow keys to highlight option, press <Return> or <Enter> to select option.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
