BayStack 450 10/100/1000 Series Switches
309978-D Rev 01 1-81
Trunk Configuration Screen Examples
This section shows examples of the MultiLink Trunk configuration screens for the
client/server configuration example shown in
Figure 1-49 on page 1-80. The
screens show how you could set up the trunk configuration screens for switches
S1 to S4. See “
Spanning Tree Considerations for MultiLink Trunks” on
page 1-93, and “MultiLink Trunk Configuration” on page 3-64 for more
information.
Trunk Configuration Screen for Switch S1
Switch S1 is set up with five trunk configurations: T1, T2, T3, T4, and T5.
Setting Up the Trunk Configuration for S1:
To set up the trunk configuration, choose MultiLink Trunk Configuration
(or press t) from the MultiLink Trunk Configuration Menu screen (Figure 1-50).
Figure 1-50. Choosing the MultiLink Trunk Configuration Screen
MultiLink Trunk Configuration Menu
MultiLink Trunk Configuration...
MultiLink Trunk Utilization...
Return to Switch Configuration Menu
Use arrow keys to highlight option, press <Return> or <Enter> to select option.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
