Using the BayStack 450 10/100/1000 Series Switch
1-100 309978-D Rev 01
Figure 1-60. Port Mirroring Port-Based Screen Example
Address-Based Mirroring Configuration
Figure 1-61 shows an example of an address-based mirroring configuration where
port 23, the designated monitor port for switch S1, is monitoring traffic occurring
between address A and address B.
Port Mirroring Configuration
Monitoring Mode: [ -> Port X or Port Y -> ]
Monitor Unit/Port: [ /23 ]
Unit/Port X: [ /25 ]
Unit/Port Y: [ /24 ]
Address A: [ 00-00-00-00-00-00 ]
Address B: [ 00-00-00-00-00-00 ]
Port mirroring configuration has taken effect.
Currently Active Port Mirroring Configuration
---------------------------------------------
Monitoring Mode: -> Port X or Port Y -> Monitor Port: 23
Port X: 25 Port Y: 24
Use space bar to display choices, press <Return> or <Enter> to select choice.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
