Using the Console Interface
309978-D Rev 01 3-53
Figure 3-19. VLAN Port Configuration Screen
Table 3-17 describes the VLAN Port Configuration screen fields.
Table 3-17. VLAN Port Configuration Screen Fields
Field Description
Unit Allows you to select the unit number (when stacking is configured) to
view or configure. To view another unit, type its unit number and press
[Enter], or press the spacebar to toggle the unit numbers. To find the unit
number for a specific switch in the stack configuration, use the Identify
Unit Numbers option (see
Ta bl e 3-1 on page 3-6).
Port Allows you to select the number of the port you want to view or
configure. To view another port, type its port number and press [Enter],
or press the spacebar to toggle the port numbers.
Filter Tagged Frames Allows you to set this port to filter (discard) all received tagged packets.
Default No
Range No, Yes
(continued)
VLAN Port Configuration
Unit: [ 1 ]
Port: [ 1 ]
Filter Tagged Frames: [ No ]
Filter Untagged Frames: [ No ]
Filter Unregistered Frames: [ No ]
Port Name: [ Unit 1, Port 1 ]
PVID: [ 1 ]
Port Priority: [ 0 ]
Tagging: [ Untagged Access ]
AutoPVID (all ports): [ Disabled ]
Use space bar to display choices, press <Return> or <Enter> to select choice.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
