Appendix E
Quick Steps to Features
If you are a system administrator with experience configuring BayStack 450
switch VLANs, ATM MDAs, MultiLink Trunking, Port Mirroring, and IGMP
Snooping, use the flowcharts on the following pages as quick configuration
guides. The flowcharts refer you to the “configuration rules” appropriate for each
feature.
The flowcharts cover the following topics:
• “Configuring 802.1Q VLANs” (page E-2)
• “Configuring Security Settings” (page E-5)
• “Configuring the BayStack 450-2M3/2S3 MDAs” (page E-15)
• “Configuring MultiLink Trunks” (page E-18)
• “Configuring Port Mirroring” (page E-19)
• “Configuring IGMP Snooping” (page E-21)
To learn more about: See:
802.1Q VLANs “Virtual Local Area Networks (VLANs)” on page 1-49.
Switch and Network Security “Security” on page 1-17.
BayStack 450-2M3/2S3 MDAs Appendix D, “ATM Overview.”
MultiLink Trunks “MultiLink Trunks” on page 1-78.
Port Mirroring “Port Mirroring (Conversation Steering)” on page 1-97.
IGMP Snooping “IGMP Snooping” on page 1-69.
