Using the Console Interface
309978-D Rev 01 3-23
Table 3-6 describes the MAC Address Table screen fields.
Table 3-6. MAC Address Table Screen Fields
Field Description
Aging Time Specifies how long a learned MAC address remains in the switch’s
forwarding database. If an entry is inactive for a period of time that exceeds
the specified aging time, the address is removed.
Default 300 seconds
Range 10 to 1,000,000 seconds
Find an Address Allows the user to search for a specific MAC address.
Default 00-00-00-00-00-00 (no MAC address assigned)
Range 00-00-00-00-00-00 to FF-FF-FF-FF-FF-FF
Port Mirroring Address A Appears only when you select any of the five address-based monitoring
modes from the Port Mirroring Configuration screen. When you enter a MAC
address in this field, it is also configured into the Port Mirroring Configuration
screen. Conversely, when you enter the MAC address from the Port Mirroring
Configuration screen, it also appears in this screen. See “
Port Mirroring
Configuration” on page 3-71 for more information.
Default 00-00-00-00-00-00 (no MAC address assigned)
Range 00-00-00-00-00-00 to FF-FF-FF-FF-FF-FF
Port Mirroring Address B Appears only when you select any of the two address-based monitoring
modes that use Address B from the Port Mirroring Configuration screen.
When you enter a MAC address in this field, it is also configured into the Port
Mirroring Configuration screen. Conversely, when you enter the MAC
address from the Port Mirroring Configuration screen, it also appears in this
screen. See “
Port Mirroring Configuration” on page 3-71 for more
information.
Default 00-00-00-00-00-00 (no MAC address assigned)
Range 00-00-00-00-00-00 to FF-FF-FF-FF-FF-FF
