Using the BayStack 450 10/100/1000 Series Switch
3-62 309978-D Rev 01
High Speed Flow Control Configuration
The High Speed Flow Control Configuration screen (Figure 3-24) allows you to
set the port parameters for installed gigabit MDAs.
Choose High Speed Flow Control Configuration (or press h) from the Switch
Configuration Menu to open the High Speed Flow Control Configuration screen.
Figure 3-24. High Speed Flow Control Configuration Screen
Table 3-21 describes the High Speed Flow Control Configuration screen fields.
Note: This screen appears only when an optional gigabit MDA is installed in
the Uplink Module slot.
High Speed Flow Control Configuration
Unit: [ 1 ]
Autonegotiation: [ Enabled ]
Flow Control: Disabled
Preferred Phy: [ Right ]
Active Phy: Right
Use space bar to display choices, press <Return> or <Enter> to select choice.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
