Using the BayStack 450 10/100/1000 Series Switch
3-94 309978-D Rev 01
ATM MDA Configuration
The ATM MDA Configuration screen (Figure 3-38) allows you to set up ATM
configuration parameters for your BayStack 450-2M3/2S3 MDA.
Certain fields in this screen may require you to reset the switch if you change the
current or default value for another value. The reset option is always preceded by a
screen prompt. Enter Yes to reset the switch; enter No to abort the option.
You can also use this screen to view the current BayStack 450-2M3/2S3 MDA:
• Hardware version
• Software version
• Hardware type
• MAC addresses for physical ports A1 and A2
Choose ATM MDA Configuration (or press a) from the ATM Configuration Menu
to open the ATM MDA Configuration screen.
Actual Physical
Port
This read-only field displays the actual physical port for the selected LEC.
Default A1
Range A1, A2
LEC Fail Over This read-only field displays the LEC Fail Over setting for the ATM MDA. You can set
the LEC Fail Over field using the ATM MDA Configuration screen (see “ATM MDA
Configuration” on page 3-94).
Table 3-33. LEC Configuration Screen Fields (continued)
Field Description
