Using the Console Interface
309978-D Rev 01 3-79
IGMP Configuration
Figure 3-33 shows an example of the IGMP Configuration screen in a stacked
configuration (when installed as a standalone switch, the screen does not display
the Unit # field designation).
Switch ports 8 and 14 of unit 1, ports 2 and 6 of unit 2, and port 16 of unit 4 are
configured to receive all IP multicast-related traffic. The configured ports are
VLAN port members of VLAN 5, and are called Static Router Ports.
Choose IGMP Configuration (or press g) from the IGMP Configuration Menu to
open the IGMP Configuration screen.
Table 3-28. IGMP Configuration Menu Options
Option Description
IGMP Configuration... Displays the IGMP Configuration screen (see “IGMP Configuration” following
this table). This screen allows you to set up IGMP configurations.
Display Multicast Group
Membership...
Displays the Multicast Group Membership screen (see “Multicast Group
Membership” on page 3-83). This screen allows you to view all IP multicast
addresses that are active in the current LAN.
Return to Switch
Configuration Menu
Exits the IGMP Configuration Menu and displays the Switch Configuration
Menu.
Note: Before configuring your switch for IGMP snooping, see “IGMP
Snooping Configuration Rules” on page 1-73.
