Nortel BayStack 450-24T - Figure 3-39. ATM MDA Software Download Screen; Table 3-35. ATM MDA Software Download Screen Fields

Using the BayStack 450 10/100/1000 Series Switch
3-98 309978-D Rev 01
Figure 3-39. ATM MDA Software Download Screen
Table 3-35 describes the ATM MDA Software Download screen fields.
Table 3-35. ATM MDA Software Download Screen Fields
Field Description
Image Filename The software image load file name.
Default Zero-length string
Range An ASCII string of up to 30 printable characters
TFTP Server IP
Address
The IP address of your TFTP load host.
Default 0.0.0.0 (no IP address assigned)
Range Four-octet dotted-decimal notation, where each octet is
represented as a decimal value, separated by a decimal point
(continued)
ATM MDA Software Download
Image Filename: [ ]
TFTP Server IP Address: [ xxx.xx.xxx.xx ]
Start TFTP transfer of MDA image: [ No ]
Enter text, press <Return> or <Enter> when complete.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
