Figure 3-45. Spanning Tree Port Configuration Screen (2 of 2)
Table 3-39 describes the Spanning Tree Port Configuration screen fields.
Table 3-39. Spanning Tree Port Configuration Screen Fields
Field Description
Unit This field appears only if the switch is participating in a stack configuration. The field
allows you to select the number of the unit you want to view. To view another unit, type its
unit number and press [Enter], or press the spacebar on your keyboard to toggle the unit
numbers.
Port Indicates the switch port numbers that correspond to the field values in that row of the
screen (for example, the field values in row 2 apply to switch port 2). Note that the values
in the Switch row affect all switch ports and, when the switch is part of a stack, the values
in the Stack row affect all ports in the entire stack.
Trunk This read-only field indicates the trunks that correspond to the switch ports specified in
the Trunk Members fields of the Trunk Configuration screen (see “
MultiLink Trunk
Configuration” on page 3-64).
(continued)
Spanning Tree Port Configuration
Unit: [ 1 ]
Port Trunk Participation Priority Path Cost State
---- ----- ------------------- -------- --------- ----------
15 [ Normal Learning ] 128 5 Forwarding
16 [ Normal Learning ] 128 5 Forwarding
17 1 [ Normal Learning ] 128 10 Forwarding
18 [ Normal Learning ] 128 10 Forwarding
19 4 [ Normal Learning ] 128 10 Forwarding
20 4 [ Normal Learning ] 128 10 Forwarding
21 [ Normal Learning ] 128 10 Forwarding
22 5 [ Normal Learning ] 128 10 Forwarding
23 5 [ Normal Learning ] 128 10 Forwarding
24 [ Normal Learning ] 128 10 Forwarding
25 2 [ Normal Learning ] 128 10 Forwarding
26 2 [ Normal Learning ] 128 10 Forwarding
27 [ Normal Learning ] 128 10 Forwarding
28 [ Normal Learning ] 128 10 Forwarding
Switch [ Normal Learning ]
Stack [ Normal Learning ]
Press Ctrl-P to display choices for ports 1-14.
Use space bar to display choices, press <Return> or <Enter> to select choice.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
