Nortel BayStack 450-24T - Figure 3-16. EAPOL Security Configuration Screen; Table 3-12. EAPOL Security Configuration Screen Options

Using the Console Interface
309978-D Rev 01 3-41
Figure 3-16. EAPOL Security Configuration Screen
Table 3-12 describes the EAPOL Security Configuration screen options.
Table 3-12. EAPOL Security Configuration Screen Options
Option Description
EAPOL Administrative
State
Allows you to enable or disable EAPOL for your switch or stack. When this
field is set to Disabled (the default state), the Operational Status for all of the
switch/stack ports is set to Authorized (no security restriction).
Default Disabled
Range Disabled, Enabled
(continued)
EAPOL Security Configuration
EAPOL Administrative State: [ Disabled ]
Unit: [ 1 ] Port: [ 1 ]
Initialize: [ No ]
Administrative Status: [ Force Authorized ]
Operational Status: Unauthorized
Administrative Traffic Control:[ Incoming and Outgoing ]
Operational Traffic Control: Incoming and Outgoing
Re-authenticate Now: [ No ]
Re-authentication: [ Disabled ]
Re-authentication Period: [ 3600 seconds ]
Quiet Period: [ 60 seconds ]
Transmit Period: [ 30 seconds ]
Supplicant Timeout: [ 30 seconds ]
Server Timeout: [ 30 seconds ]
Maximum Requests: [ 2 ]
Use space bar to display choices, press <Return> or <Enter> to select choice.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
