Using the BayStack 450 10/100/1000 Series Switch
3-42 309978-D Rev 01
Unit Allows you to select the unit number (when stacking is configured) to view or
configure. To view or configure another unit, type its unit number and press
[Enter], or press the spacebar to toggle the unit numbers. If you set this field
value to ALL, other screen field values you modify apply to all stack ports.
Default 1
Range 1,2,3,4,5,6,7,8,ALL
Port Allows you to select a specified unit’s (see preceding Unit field) port number
to view or configure. To view or configure another port, type its port number
and press [Enter], or press the spacebar to toggle the port numbers. If you
set this field value to ALL, other screen field values you modify apply to all
ports for the specified unit.
The ALL value is also useful when you want to apply modified field values to
most of, but not all of, your switch’s ports. For example, if you want to apply
modified field values to 23 of your switch’s 24 ports, it may be easier to apply
the ALL value in the Port field, and then reconfigure the single port back to its
original values.
Default 1
Range 1 to 28,ALL
Initialize Allows you to activate EAPOL authentication for the specified unit/port.
Default No
Range No,Yes
Administrative Status Allows you to set the EAPOL authorization status for the specified unit/port.
• Force Authorized means the specified unit/port authorization status is
always authorized.
• Force Unauthorized means the specified unit/port authorization status is
always Unauthorized.
• Auto means the specified unit/port authorization status depends on the
EAP authentication results.
Default Force Authorized
Range Force Authorized,Force Unauthorized,Auto
Operational Status A read-only field that shows the current authorization status for the specified
unit/port. This read-only field does not appear when the Unit/Port field value
is set to ALL.
Default Authorized
Range Authorized,Unauthorized
(continued)
Table 3-12. EAPOL Security Configuration Screen Options (continued)
Option Description
